DESCRIPTION:
|
2-way powered speaker
|
BUILT IN POWER AMPLIFIER:
|
2 x 30W RMS; 2 x 60W continuous program
|
FREQUENCY RANGE:
|
50Hz to 20kHz @ -10dB
|
FREQUENCY RESPONSE:
|
90Hz to 20kHz @ ±3dB |
WOOFER: |
5 1/4” polypropylene cone with rubber edge woofer |
TWEETER |
1" Titanium dome tweeter |
SENSITIVITY: |
87dB SPL, 1W@1m for 1k Hz |
MAX SPL: |
Continuous: 102dB Peak: 105dB |
POWER SOURCE: |
100-240V AC 50/60Hz |
CROSSOVER FREQUENCY: |
2kHz |
DIRECTIVITY FACTOR (Q): |
4.0 averaged 1kHz to 10kHz @ 100 Degrees |
DIRECTIVITY INDEX (DI): |
6.0dB averaged 1kHz to 10kHz @ 100 Degrees |
INPUT CONNECTORS: |
Line level unbalanced stereo audio on a 3.5mm TRS connector |
|
Line level balanced stereo audio on a terminal block connector |
|
Line level unbalanced stereo audio on left and right RCA connectors |
OUTPUT CONNECTORS: |
Speaker (to connect to the external passive speaker)
|
|
3.5mm mini jack lineout for optional sub-woofer
|
|
3.5mm mini jack Loop output
|
DAMPING FACTOR:
|
>100 @ 8Ω/400Hz
|
S/N RATIO:
|
> 83dB
|
THD:
|
< 0.2%
|
CONTROLS:
|
Volume, bass and treble
|
INPUT POWER:
|
ON,OFF or AUTO
|
STANDBY MODE POWER CONSUMPTION:
|
0.3W
|
INPUTS SIGNAL FOR SYSTEM “WAKE- UP” FROM STANDBY MODE:
|
≥10mV
|
MATERIALS:
|
Aluminum grill, steel brackets, ABS cabinet
|
WEIGHT PER SINGLE SPEAKER:
|
3,8KG
|
WEIGHT WITH MOUNTING KIT:
|
3,9KG
|
SHIPPING WEIGHT (FOR PAIR):
|
8,15KG
|
DIMENSIONS:
|
19.2cm x 18.5cm x 28.5cm (7.2” x 6.7” x 9.6”) W, D, H
|
DIMENSIONS WITH MOUNTING BRACKETS:
|
19.2cm x 23.5cm x 28.8cm (7.2” x 6.7” x 9.6”) W, D, H
|
HOLE SPACING THIRD PARTY MOUNTING BRACKETS:
|
70mm using M6 bolts
|
INSTALLATION CLEARANCE:
|
Front panel to wall (with mounting bracket): 24cm (9.5in) Back panel to wall (with mounting bracket): 4.5cm (1.8in)
|
INCLUDED ACCESSORIES:
|
1 pair of U-shaped rotating mounting brackets
|
|
3m (9.84ft) power cord; 4m (13.12ft) loudspeaker cable; and a 3m (9.84ft) 3.5mm to 2 RCA cable
|
OPTIONAL ACCESSORIES:
|
Third party mounting brackets, for example K&M 24141
|
COLORS:
|
Available in white or black
|
CERTIFICATIONS
|
CE, RoHS
|
